Engineering Design
Thermal FEA and CNC-Ready Design
A steady-state thermal study and manufacturing-ready CAD, shown as two supporting engineering proofs.
Stack: ANSYS 2023 R1 · SolidWorks
- ANSYS
- Steady-State Thermal
- FEA
- CNC
- DXF
Two supporting engineering studies that demonstrate analysis and manufacturing preparation.
The thermal study is a steady-state finite-element analysis used to visualise total heat flux across a meshed multi-block geometry and identify high-flux regions for engineering review. The displayed result reaches approximately 10.57 kW/m².
The CNC work covers CAD and cutting-file preparation for furniture components, including 2D cutting drawings, part-wise layouts and dimensions, delivered in the agreed formats.
What we built
- Steady-state thermal analysis with meshed multi-block geometry
- Total heat flux distribution and high-flux region identification
- CNC-ready 2D cutting drawings and part-wise layouts
- Deliverables in DXF, DWG and PDF
Gallery
